Poles

PV series

Conical pole in welded and unbeaded steel

Conical PV pole for public lighting in welded and unbeaded steel, made in a single section bent longitudinally. Conical tip in drawn aluminium with a plastic end. The pole is equipped with a standard shank with a diameter of 60 mm.

Go to download

Circular section Made in Italy

Conical PV pole for public lighting in welded and unbeaded steel, made in a single section bent longitudinally. Conical tip in drawn aluminium with a plastic end. The pole is equipped with a standard shank with a diameter of 60 mm.

Circular section

Made in Italy

Characteristics

PV pole for street and urban public lighting. Conical shape, made of welded and unbeaded steel. The pole has been progettato in a single section bent longitudinally. Conical tip in drawn aluminium with a plastic end. The pole is equipped with a standard shank with a diameter of 60 mm.

Choose from the five available heights:

PV 6

Light point height 5900 mm
Size at the base Ø 121 mm
Head size Ø 60 mm
Attachment tang Ø 60 mm

PV 7

Light point height 6900 mm
Size at the base Ø 131 mm
Head size Ø 60 mm
Attachment tang Ø 60 mm

PV 8

Light point height 7900 mm
Size at the base Ø 141 mm
Head size Ø 60 mm
Attachment tang Ø 60 mm

PV 9

Light point height 8900 mm
Size at the base Ø 151 mm
Head size Ø 60 mm
Attachment tang Ø 60 mm

PV 10

Light point height 9900 mm
Size at the base Ø 161 mm
Head size Ø 60 mm
Attachment tang Ø 60 mm

Available colours

Hot dip galvanizing according to ISO 1461 and subsequent brushing to ensure a perfect surface finish. Polyester powder coating.

Graphite

Code 01

Black

Code 02

Silver

Code 03

Sand

Code 04

Colore RAL

RAL colours

On request

Products compatible with the PV pole

Standard spigot for fixture with connection Ø 60 mm

ARMODUE

COMPASS

Q-DROME

STYLO

ITALO
